| Machine Type | A3 Monochrome Laser Multifunctional |
| Core Functions | Print, Copy, Scan, Send, Store and Optional Fax |
| Processor | Canon Dual Custom Processor (Shared) |
| Control Panel | Standard: 25.654cm (10.1in) TFT LCD WSVGA Colour Touch panel Optional: 26.416cm (10.4in) TFT LCD SVGA Colour Upright Touch panel |
| Memory | Standard: 3.0Gb RAM |
| Hard Disk Drive | Standard*1: 320Gb (available disk space: 250Gb) Optional: 250Gb, 1TB |
| Mirroring Hard Disk Drive | Optional |
| Interface Connection | NETWORK Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n) Optional: NFC, Bluetooth Low EnergyOTHERS Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1 Optional: Serial Interface, Copy Control Interface |
| Paper Supply Capacity (A4, 80g/m²) | Standard: 4 200 sheets 100-sheet Multi-purpose tray x 1 1 500-sheet Paper Deck x 2 550-sheet Paper Cassette x2Maximum: 7 700 sheets (with Paper Deck Unit-E1 or POD Deck Lite-C1) |
| Paper Output Capacity (A4, 80g/m²) | 250 Sheets (with Copy Tray-R2) Maximum: 3 500 Sheets (with Staple Finisher-AC1 or Booklet Finisher-AC1) |
| Finishing Capabilities | With options: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, Document Insertion, Z-fold, C-fold |
| Supported Media Types | Multi-purpose tray: Thin, Plain, Recycled, Colour, Heavy, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, TabPaper Decks (Right/Left): Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, LetterheadPaper Cassettes (Upper/Lower): Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, Letterhead, Tab*2 |
| Supported Media Sizes | Multi-purpose tray: Standard size: A3, A4, A4R, A5*3, A5R, A6R*4, B4, B5, B5R Custom size: 100.0 x 148.0 mm to 297.0 x 487.7 mm Free size: 100.0×148.0mm to 297.0mm×487.7mmPaper Decks (Right/Left): Standard size: A4, B5Paper Cassettes (Upper/ Lower): Standard size: A3, A4, A4R, A5R, B4, B5, B5R Custom size: 139.7 x 182.0 mm to 297 x 487.7 mm |
| Supported Media Weights | Multi-purpose tray: 52 to 256g/m² Paper Deck (Right/Left): 52 to 220g/m² Paper Cassette (Upper/Lower): 52 to 220g/m² Duplex: 52 to 220g/m² |
| Warm-up Time | Quick Start-up Mode: 4ss or less*5 From Sleep Mode: 30s or less From Power On: 30s or less*6 |
| Dimensions (W x D x H) | 670 x 770 x 1 185 mm With optional Upright Control Panel: 1 170 x 770 x 1 252mm |
| Installation Space (W x D) | Basic: 1 533 x 1 353mm (with Multi-purpose tray/upper-right cover open + Front cover open + Copy Tray) Fully configured: 2 436 x 1 353mm (with POD Deck Lite-C1 + Document Insertion/Folding Unit-J1 + Booklet Finisher-AC1/Staple Finisher-AC1 + Main unit Front cover open ) |
| Weight | iR-ADV DX 6780i/6765i/6755i: Approx. 219kg*7, Approx. 223kg*8 |
